Dyno-Cams SKU: DC-AN-308-TSB

Camshaft, 308 Grind, Welded Lobe Billet, Animal Core

Regular price $184.00 USD
Regular price Sale price $184.00 USD
Sale Sold out
Shipping calculated at checkout.


Description:

Description

  • The 308 is has a very wide power band, is easy on the valve train, and works very well in a modified engine build. This cam will require an upgraded spring package, billet rod, and billet flywheel.
  • Tool Steel Billet cores are the best choice in high RPM applications.
  • The two piece design of the Tool Steel Billet core allows you to advance or retard the cam to meet your application needs.



Specs

Engine: Briggs Intek OHV
Recommended Class: Modified
Target (MAX) RPM: 8500
Spring Pressure (In / Ex): 36 lbs
Valve Lash (In/Ex): .003"
Ignition Timining: 30-32 Deg BTDC



Profile

  Intake Exhaust
Open: 53.5 BTDC 91.0 BBDC
Close: 91.0 ABDC 55.1 ATDC
Lift: .308" .308"
C/L: 108.0 ATDC 108.0 BTDC
DUR @ 50: 244.2 Deg 244.6 Deg

Link to Cam Card


Link to Timing Mark Alignment
